Table 1 CU/XLPE/CAS/PVC(HDPE)
| Nominal CSA mm2 | Approx.Conductor diameter mm | Nominal Insulation Thickness mm | Outer Sheath thickness mm | Max. DC resistance at 20℃ Ω/km |
| 800 | 34 | 34 | 6 | 0.0221 |
| 800(SM) | 35.6 | 34 | 6 | 0.0221 |
| 1000(SM ) | 39.7 | 33 | 6 | 0.0176 |
| 1200(SM) | 42.8 | 33 | 6 | 0.0151 |
| 1400(SM) | 46.4 | 32 | 6 | 0.0129 |
| 1600(SM) | 49.2 | 32 | 6 | 0.0113 |
| 1800(SM) | 51.4 | 31 | 6 | 0.0101 |
| 2000(SM) | 54.5 | 31 | 6 | 0.009 |
| 2500(SM) | 60.9 | 31 | 6 | 0.0083 |
